Razor barbed wire


Introduction and Application

Razor wire is made with hot-dipped galvanized sheet or stainless steel sheet to perforate the sharpe blade and high tension galvanized steel wire or stainless steel wire as core wire. With the unique shape, razor wire is not easy to touch, and get the excellent protection. Razor wire fence as a new type of protection fence, is made of straight-blade netting welded together. It is mainly used for garden apartments, institutions, prisons, post, border protection and other confinement; also be used for security windows, high fence, fence.
Feature

  • High protection, it is almost impossible to climb.
  • High-strength steel core very difficult to cut off.
  • Powerful security fence barriers neat appearance.
  • Extremely simple to install, needs three to four to install molding.
  • No secondary use, so he will not be stolen.
  • Anti-corrosion, aging, sunscreen, weather.

Treatment Process
The use of steel (blades) attached to the hot stamping molding package galvanized steel wire (wire) above by the sharp angular sheet galvanized steel or stainless steel blade to do, to do high-tension steel wire combination.
Materials
Core Wire Materials: Use the high- quality hot-dipped galvanized high carbon steel wire, hot-dipped galvanized medium carbon steel wire, stainless steel wire, etc.
Razor Wire Materials: Use the high- quality hot-dipped galvanized steel sheet, stainless steel sheet.
Main Types
Razor barbed wire fence, according to the way of installment, has three types: Sprial razor wire fence, Straight razor wire fence, Flat razor wire fence and so on.

  • Sprial Razor Wire

Spiral razor wire is also known as snake bellied fence. It is divided into two types: single concertina razor wire and spiral cross type razor wire. Single concertina razor wire without using the clip can be installed in accordance with its expanded natural form. Spiral cross-type razor wire is made with stainless steel sheet and galvanized steel with a strong clip between two razors, It is beautiful and practical after the commencement of branding cross-shaped.

  • Flat Razor Wire

Flat razor wire is a new application form, it is the lap-style flat blade pressed into plate-like gill nets, or gill nets, two laps after the cross with the wrong voltage level to use, aesthetically pleasing and practical, with straight blade with the use of gill nets to form a straight line on the plate under the fence, or just flat gill nets form a protective wall. It is mainly used in residential, warehouses, livestock factories, farms, mines, prisons, and other defense powerhouse.

  • Straight Razor Wire

Straight razor wire is also known as welded razor wire. With the blade-type cross-welding forming a straight line, if someone wants to climb crossing, barbed wire mesh of the blade sharp blade, can not shake hands, feet can not climb, and resolutely prevent people crossed protective walls. It has the strong effect of intimidation and prevent, both beautiful and practical. Mainly used in airports, military bases, substation, a variety of fences, oil depots, factories and other fields.



Blade Specification

Blade Forms

Blade Thickness

Core Wire Dia.

Blade Length

Blade Width

Blade Space

BTO-10

0.5±0.05

2.5±0.1

10±1

13±1

26±1

BTO-12

0.5±0.05

2.5±0.1

12±1

15±1

26±1

BTO-18

0.5±0.05

2.5±0.1

18±1

15±1

33±1

BTO-22

0.5±0.05

2.5±0.1

22±1

15±1

34±1

BTO-28

0.5±0.05

2.5

28

15

45±1

BTO-30

0.5±0.05

2.5

30

18

45±1

CBT-60

0.6±0.05

2.5±0.1

60±2

32±1

100±2

CBT-65

0.6±0.05

2.5±0.1

65±2

21±1

100±2


Razor Barbed Wire Definition



  Specification

OD

Loops

Length of Covering

Type & Standard

Notes

450mm

33

8M

CBT-65

Single coil

500mm

41

10M

CBT-65

Single coil

700mm

41

10M

CBT-65

Single coil

960mm

53

13M

CBT-65

Single coil

500mm

102

16M

BTO-10.15.22

Cross type

600mm

86

14M

BTO-10.15.22

Cross type

700mm

72

12M

BTO-10.15.22

Cross type

800mm

64

10M

BTO-10.15.22

Cross type

960mm

52

9M

BTO-10.15.22

Cross type
